Color Gradients

Color gradients are smooth blendings of different colors, specified by color stops along a control vector. An application example is shown in the optical flow tutorial.

viren2d.ColorGradient

Base class for LinearColorGradient and RadialColorGradient.

viren2d.LinearColorGradient

Gradient definition for linear color blending along a line.

viren2d.RadialColorGradient

Radial gradient between two circles.

Gradient Base Class

class viren2d.ColorGradient

Base class for LinearColorGradient and RadialColorGradient.

This class should not be instantiated directly, refer to the derived classes instead.

Corresponding C++ API: viren2d::ColorGradient.

Linear Gradient

class viren2d.LinearColorGradient

Gradient definition for linear color blending along a line.

Represents a linear gradient along the control vector (used to add color stops) from a line’s start point to its end point. After initialization, the color stops have to be added via add_color_stop() or add_intensity_stop().

Corresponding C++ API: viren2d::LinearColorGradient.

Example

>>> grad = viren2d.LinearColorGradient((0, 0), (200, 200))
>>> grad.add_color_stop(0.1, 'crimson')
>>> grad.add_color_stop(0.5, 'teal-green')
>>> grad.add_color_stop(0.9, 'navy-blue')

Exemplary linear color gradients

Methods:

__init__

Initializes the gradient for linear blending along the line.

add_color_stop

Adds a color stop to the gradient.

add_intensity_stop

Adds an intensity/grayscale stop to the gradient.

is_valid

Returns true if this color gradient can be rendered, i.e. if it has at least 2 color stops.

mask

Renders this color gradient as a double-precision mask of the specified size.

visualization

Renders this color gradient onto an image of the specified size.
__init__(self: viren2d.LinearColorGradient, pt1: viren2d.Vec2d, pt2: viren2d.Vec2d) → None

Initializes the gradient for linear blending along the line.

Parameters:

  • pt1 – Start position, i.e. at \(\text{offset} = 0\), as Vec2d.

  • pt2 – End position, i.e. at \(\text{offset} = 1\), as Vec2d.

add_color_stop(self: viren2d.ColorGradient, offset: float, color: viren2d.Color) → bool

Adds a color stop to the gradient.

Parameters:

  • offset – The offset \(\in [0,1]\) is the location along the gradient’s control vector.

  • color – The Color at the specified offset.

Returns:

True if the color stop was added, false if the inputs were invalid (for example, out-of-range) which will be detailed in a logged warning message.

Example

>>> grad.add_color_stop(0.1, 'crimson')
>>> grad.add_color_stop(0.9, 'navy-blue')
add_intensity_stop(self: viren2d.ColorGradient, offset: float, intensity: float, alpha: float = 1.0) → bool

Adds an intensity/grayscale stop to the gradient.

Parameters:

  • offset – The offset \(\in [0,1]\) is the location along the gradient’s control vector.

  • color – The intensity/grayscale value \(\in [0,1]\) at the specified offset.

  • alpha – The opacity \(\in [0,1]\) at this stop.

Returns:

True if the intensity stop was added, false if the inputs were invalid (for example, out-of-range) which will be detailed in a logged warning message.

Example

>>> grad.add_intensity_stop(0.1, 0.0)
>>> grad.add_intensity_stop(0.9, 1.0)
is_valid(self: viren2d.ColorGradient) → bool

Returns true if this color gradient can be rendered, i.e. if it has at least 2 color stops.

mask(self: viren2d.ColorGradient, width: int, height: int, channels: int, fill_color: viren2d.Color = viren2d.Color(red=0, green=0, blue=0, alpha=0)) → viren2d.ImageBuffer

Renders this color gradient as a double-precision mask of the specified size.

Corresponding C++ API: viren2d::ColorGradient::Mask.

Parameters:

  • width – Width of the output mask in pixels.

  • height – Height of the output mask in pixels.

  • channels – Number of output channels. Must be either 1, 3, or 4. If a single-channel mask is requested, only the red component of the color stops will contribute to the output mask.

  • fill_color – The Color used to initialize the output mask before rendering the gradient.

Returns:

An ImageBuffer of type numpy.float64 with values \(\in [0, 1]\) and channels layers/channels.

Example

>>> grad = viren2d.LinearColorGradient((0, 0), (200, 200))
>>> grad.add_color_stop(0.1, 1.0)
>>> grad.add_color_stop(0.5, 0.5)
>>> grad.add_color_stop(0.9, 1.0)
>>> mask = grad.mask(
>>>     width=200, height=200, channels=1, fill_color="black!0")
visualization(self: viren2d.ColorGradient, width: int, height: int, channels: int = 3, fill_color: viren2d.Color = viren2d.Color(red=1, green=1, blue=1, alpha=1)) → viren2d.ImageBuffer

Renders this color gradient onto an image of the specified size.

Corresponding C++ API: viren2d::ColorGradient::Visualization.

Parameters:

  • width – Width of the output image in pixels.

  • height – Height of the output image in pixels.

  • channels – Number of output channels, must be either 3 or 4.

  • fill_color – The Color used to initialize the output image before rendering the gradient.

Returns:

A 3- or 4-channel ImageBuffer of type numpy.uint8.

Example

>>> grad = viren2d.LinearColorGradient((0, 0), (200, 200))
>>> grad.add_color_stop(0.1, 'crimson!80')
>>> grad.add_color_stop(0.5, 'teal-green!60')
>>> grad.add_color_stop(0.9, 'navy-blue!80')
>>> vis = grad.visualization(
>>>     width=200, height=200, channels=3, fill_color="white")

Radial Gradient

class viren2d.RadialColorGradient

Radial gradient between two circles.

Represents a radial gradient between two circles. The control vector (for adding color stops) is from any point on \(\text{circle}_1\) to the corresponding point on \(\text{circle}_2\). After initialization, the color stops have to be added via add_color_stop() or add_intensity_stop().

Corresponding C++ API: viren2d::RadialColorGradient.

Example

>>> grad = viren2d.RadialColorGradient(
>>>     (50, 50), 10, (50, 50), 40)
>>> grad.add_color_stop(0.0, 'freesia')
>>> grad.add_color_stop(0.9, 'navy-blue')

Exemplary radial color gradients

Methods:

__init__

Initializes the radial gradient.

add_color_stop

Adds a color stop to the gradient.

add_intensity_stop

Adds an intensity/grayscale stop to the gradient.

is_valid

Returns true if this color gradient can be rendered, i.e. if it has at least 2 color stops.

mask

Renders this color gradient as a double-precision mask of the specified size.

visualization

Renders this color gradient onto an image of the specified size.
__init__(self: viren2d.RadialColorGradient, center1: viren2d.Vec2d, radius1: float, center2: viren2d.Vec2d, radius2: float) → None

Initializes the radial gradient.

Parameters:

  • center1 – Center of \(\text{circle}_1\) as Vec2d.

  • radius1 – Radius of \(\text{circle}_1\).

  • center2 – Center of \(\text{circle}_2\) as Vec2d.

  • radius2 – Radius of \(\text{circle}_2\).

add_color_stop(self: viren2d.ColorGradient, offset: float, color: viren2d.Color) → bool

Adds a color stop to the gradient.

Parameters:

  • offset – The offset \(\in [0,1]\) is the location along the gradient’s control vector.

  • color – The Color at the specified offset.

Returns:

True if the color stop was added, false if the inputs were invalid (for example, out-of-range) which will be detailed in a logged warning message.

Example

>>> grad.add_color_stop(0.1, 'crimson')
>>> grad.add_color_stop(0.9, 'navy-blue')
add_intensity_stop(self: viren2d.ColorGradient, offset: float, intensity: float, alpha: float = 1.0) → bool

Adds an intensity/grayscale stop to the gradient.

Parameters:

  • offset – The offset \(\in [0,1]\) is the location along the gradient’s control vector.

  • color – The intensity/grayscale value \(\in [0,1]\) at the specified offset.

  • alpha – The opacity \(\in [0,1]\) at this stop.

Returns:

True if the intensity stop was added, false if the inputs were invalid (for example, out-of-range) which will be detailed in a logged warning message.

Example

>>> grad.add_intensity_stop(0.1, 0.0)
>>> grad.add_intensity_stop(0.9, 1.0)
is_valid(self: viren2d.ColorGradient) → bool

Returns true if this color gradient can be rendered, i.e. if it has at least 2 color stops.

mask(self: viren2d.ColorGradient, width: int, height: int, channels: int, fill_color: viren2d.Color = viren2d.Color(red=0, green=0, blue=0, alpha=0)) → viren2d.ImageBuffer

Renders this color gradient as a double-precision mask of the specified size.

Corresponding C++ API: viren2d::ColorGradient::Mask.

Parameters:

  • width – Width of the output mask in pixels.

  • height – Height of the output mask in pixels.

  • channels – Number of output channels. Must be either 1, 3, or 4. If a single-channel mask is requested, only the red component of the color stops will contribute to the output mask.

  • fill_color – The Color used to initialize the output mask before rendering the gradient.

Returns:

An ImageBuffer of type numpy.float64 with values \(\in [0, 1]\) and channels layers/channels.

Example

>>> grad = viren2d.LinearColorGradient((0, 0), (200, 200))
>>> grad.add_color_stop(0.1, 1.0)
>>> grad.add_color_stop(0.5, 0.5)
>>> grad.add_color_stop(0.9, 1.0)
>>> mask = grad.mask(
>>>     width=200, height=200, channels=1, fill_color="black!0")
visualization(self: viren2d.ColorGradient, width: int, height: int, channels: int = 3, fill_color: viren2d.Color = viren2d.Color(red=1, green=1, blue=1, alpha=1)) → viren2d.ImageBuffer

Renders this color gradient onto an image of the specified size.

Corresponding C++ API: viren2d::ColorGradient::Visualization.

Parameters:

  • width – Width of the output image in pixels.

  • height – Height of the output image in pixels.

  • channels – Number of output channels, must be either 3 or 4.

  • fill_color – The Color used to initialize the output image before rendering the gradient.

Returns:

A 3- or 4-channel ImageBuffer of type numpy.uint8.

Example

>>> grad = viren2d.LinearColorGradient((0, 0), (200, 200))
>>> grad.add_color_stop(0.1, 'crimson!80')
>>> grad.add_color_stop(0.5, 'teal-green!60')
>>> grad.add_color_stop(0.9, 'navy-blue!80')
>>> vis = grad.visualization(
>>>     width=200, height=200, channels=3, fill_color="white")
